Bosch nds-5703-f360le flexidome panoramic 5100i IR 360 ° panoramic camera
360 ° panoramic coverage, 6MP and 12MP clarity, leaving no blind area
With integrated IR and high dynamic range, it is optimized for various light conditions
Front end or client distortion correction for easy integration and flexible viewing and recording
Built in enhanced intelligent video analysis and audio AI can trigger relevant alarms and quickly retrieve data
It adopts compact design, has anti-damage protection and can withstand various climatic conditions
Flexidome panoramic 5100i IR is a concealed and beautiful panoramic indoor and outdoor surveillance camera. It adopts stereo photography panoramic lens with 360 ° full coverage and no blind area. It is suitable for monitoring applications that need to cover a wide area in a detailed view. The camera provides complete situational awareness and high-definition enlarged images. High end system on chip (SOC) provides distortion correction function, which can be easily integrated and flexibly viewed and recorded. The built-in enhanced intelligent video analysis further enriches the complete situational awareness function and can trigger relevant alarms. The audio AI can understand the sound it captures. The camera has integrated IR, which can flexibly control the infrared intensity of multiple areas to avoid infrared saturation. In addition, it has a wide variety of inputs and outputs, such as alarm and HDMI, which are suitable for all kinds of applications. The camera adopts ik10 and IP66 design, with anti-damage protection and can withstand various climatic conditions.
function
The maximum 12MP sensor definition camera provides 6MP or 12MP sensor configuration options, which can be optimized according to the required level of detail. Both options provide a frame rate of 30 FPs to ensure that moving objects in the scene can be captured in real time. Considering the panoramic projection, the camera provides 4.5mp and 9mp effective definition. Combined with the stereo camera lens in these cameras, the definition of the edge area of the image can also be improved. Panoramic view and enhanced intelligent video analysis. Bosch enhanced intelligent video analysis software is combined with panoramic view to create a powerful monitoring tool and enrich the complete situation awareness function. With i-tracking, you can continuously track the movement in the whole panorama. There is no need to switch from one camera to another for tracking, which significantly simplifies motion analysis.
The system reliably detects, tracks and analyzes objects and notifies you when predefined alarms are triggered. A series of intelligent alarm rules simplify complex tasks and greatly reduce false positives.
It can divide moving objects into four different categories: people, cars, bicycles and trucks. Designed for harsh environments. This technology can effectively avoid false triggering caused by challenging environments such as snow, wind (shaking trees), rain, hail and water surface reflection.
Calibration is fast and easy - just enter the installation height of the camera. The internal gyroscope / accelerometer sensor can provide the remaining information to accurately calibrate the video analysis.
Camera Trainer
The camera trainer program uses machine learning technology. The user can specify the object of interest. The camera will form a targeted detector based on the examples of target object and non target object. Unlike the intelligent video analytics application, which detects moving objects, the camera trainer program detects moving and stationary objects and classifies them on the spot. With configuration manager, you can configure the camera trainer program using live video and video from the corresponding camera. The resulting targeted detectors can be downloaded and uploaded for distribution to other cameras. A free license is required to activate the camera trainer program.
Audio AI
The camera is equipped with an integrated microphone array composed of three digital microphones for audio analysis and audio AI. It provides event alarm functions, such as giving an alarm in case of broken glass, detection of gunshot, scream or other high decibel noise. The camera can not only classify the sound, but also judge the approximate sound location. There is no need to record audio because you can only check the sound characteristics.
If required by local law, the microphone can be permanently blocked by a security license key.
Audio AI is under development, so some functions may not be available or performance may be limited at the time of release.
Distortion correction
The lens captures a circular image. Our distortion correction software can convert this circular image into several different distortion free rectangular views. To speed up system integration, you can choose to perform edge distortion correction in the camera or client distortion correction on an external platform.
Future firmware versions will provide camera distortion correction. The front end distortion correction in the camera provides three separate video channels at the same time:
? full panorama (Video 1 channel)
? distortion corrected view mode (Video 2 channels)
? e-ptz (video 3-channel)
For Video 2 channels, different view modes can be selected. Your choice depends on the clarity you need and the way you want to view the distortion corrected image.
View mode, the following view modes can be selected on the camera or client:
HDMI output
The camera has 1080p HDMI output, which can be streamed to the public display in real time. It is suitable for retail merchants or local video playback. Through the micro HDMI connector, the camera can display a complete panorama. With the coming firmware version, it will be able to flexibly display the distortion corrected view mode.
High dynamic range
The camera has a high dynamic range. Using multiple exposure process, you can capture more details in bright and dark areas at the same time, even in the same scene. In this way, you can easily distinguish between objects and features, such as a face with a bright backlight.
The actual dynamic range of the camera is measured using photoelectric conversion function (OECF) analysis according to IEC 62676 Part 5. Use this method to provide standardized measurements for comparison with other cameras.
Dori coverage
Dori (detection, observation, recognition and identification) is a standard system (en-62676-4) used to define the ability of people watching video to distinguish people or objects in the shooting area. For these standards, the maximum distance that can be achieved by the camera / lens combination is as follows:
When installed at a height of 3 meters (10 feet), the camera has four levels of coverage radius of Dori for the characters in the scene:
E-ptz and region of interest
Remote e-ptz (electronic pan, pitch and zoom) control allows you to select specific areas of the entire panorama. When on-board distortion correction is enabled, the region of interest (ROI) can be easily defined and the most interesting part of the scene can be monitored separately. High definition ensures that details are not lost when using electronic zoom.
Compared with ordinary PTZ camera, the e-ptz function of panoramic camera has some advantages. Since the camera will not move, the camera itself will not attract the user's attention or interfere with the user. Situational awareness can be preserved even when a specific target object is magnified. The efficient and reliable e-ptz function can be used for browsing, and a variety of presets can be used to set the camera patrol route.
I-tracking can also track people in the whole field of view of the camera.
Recording accurately as needed, the camera provides a full definition circular image for recording, even if you only view part of the scene. This means that you can perform retrospective distortion correction and Analysis on the entire coverage area, and then zoom in on the target area or object. With front-end distortion correction, you can also choose to record only the relevant parts of the scene, which helps to significantly reduce the bit rate.
Scene mode
The user interface of the camera is very intuitive and easy to configure quickly and easily. Multiple configurable preset modes are provided, which are optimized for a variety of application scenarios. Different scene modes can be selected for different scenes such as sodium lighting or low light environment. Front end video insert the memory card into the card slot to store up to 2 TB of local alarm video. Pre alarm recording in RAM can reduce the occupation of recording bandwidth on the network and prolong the effective service life of memory card. With advanced front-end recording, it can provide the most reliable storage solution due to the combination of the following functions:
? industrial grade SD card support for extreme life
? health monitoring of industrial grade SD card can provide early service indication.
Future firmware versions will provide front-end video recording.
data security
Special measures must be taken to ensure the highest level of security for equipment access and data transmission. Three level password protection with security recommendations allows users to customize device access. Web browser access can be protected using HTTPS, and firmware updates can also be protected through authenticated secure uploads. The camera is equipped with built-in secure element (SE) hardware, which mainly provides trusted platform modules
(TPM) function to ensure a high level of data security and privacy protection. Combined with public key infrastructure (PKI) support, it provides excellent protection against malicious attacks. Support the maximum length of 4096 bits RSA encryption key, which can ensure the data security after 2030. 802.1x network authentication using EAP / TLS supports tls1 2 and an updated Password Suite including AES 256 encryption. Advanced Certificate
Processing provides:
? pre installed Bosch original equipment certificate
? self signed unique certificate automatically created when needed
? client and server certificates for authentication
? client certificate as authentication credential
? certificate with encrypted private key
Modular accessories
A complete series of modular accessories are available, which can keep the design consistent even if the camera models and installation methods are different. Optional products include: wall or pipe mounting base, and a monitoring power box with optional power supply and optical fiber. There is also a conduit adapter that can be installed on a concrete wall or ceiling.
H. 265 high efficiency video coding
The camera is designed with H.264 and h.265/hevc coding platforms with high efficiency and excellent performance. It can transmit high-quality and high-definition video with ultra-low network load. H. The coding efficiency of 265 is doubled, which is the preferred compression standard for IP video monitoring system.
The system is integrated and meets the onvif standard. The camera meets the specifications of onvif profile s, onvif profile g, onvif profile m and onvif profile t. For the h.265 configuration, the camera also supports media service 2, which is part of onvif profile t. Compliance with these standards ensures interoperability between network video products produced by different manufacturers.
Third party integrators can easily access the internal functions of the camera for integration into large projects. For more information, please visit the Bosch integration Partner Program (IPP) website (IPP. Boschsecurity. Com).
Cloud based services
The camera supports sending JPEG to four different accounts based on time or alarm. These accounts can access FTP servers or cloud based storage facilities (for example, Dropbox). In addition, video clips or JPEG images can also be exported to these accounts.
You can set alarms to trigger email or SMS notifications so that you are always aware of abnormal events.
Bosch remote portal
Bosch remote portal, a secure cloud infrastructure, can be used to manage networked Bosch devices. From the Bosch remote portal, you can:
? complete the initial configuration of networked Bosch equipment (online or offline).
? update the firmware of a single or multiple devices.
? management certificate.
? monitor the operation of networked Bosch equipment.
Two way call and built-in microphone
The two-way call function allows the operator to communicate with visitors or intruders through external audio line input and output. You can also capture clear voice through an integrated microphone. Through the integrated microphone or external microphone, the audio detection function can be used to generate an alarm to remind the security personnel to take action more quickly and proactively. If required by local law, the microphone can be deactivated through a security license key.
It is rainproof, dustproof and damage proof, and can operate reliably in a wide temperature range. It is suitable for indoor and outdoor occasions.
The rugged camera design conforms to IP66 and ik10 standards, which can protect the camera from rain and dust, and prevent malicious damage.
The camera can operate in a wide ambient temperature range from - 40 ° C to + 55 ° C (- 40 ° f to 131 ° f).
Certification standard
Standard type
Radiation en 55032
CFR 47 FCC Part 15, class A
Environmental standard EN IEC 63000: 2018
EN 50130-5: 2011
RoHS EU, 2011 / 65 / EU and 2015 / 863 / EU
Standard type
WEEE EU、2012/19/EU
NEMA TS-2 chapter 2.1
Immunity standard EN 50121-4
EN 50130-4
Marking CE, FCC, UL, WEEE, RCM, VCCI
Cmim, ukca, China RoHS
Safety en 62368-1
EN 60950-22
UL 60950-22
UL 62368-1, 2nd Edition
CSA C22. 2 No. 62368-1-14, 2nd Edition
Image performance IEC 62676-5
Comply with onvif standards en 50132-5-2 and en 62676-2
Impact protection en 62262 (ik10)
Waterproof and dustproof en 60529 (IP66) and ul50e (NEMA type 4x)
Infrared light IEC 62471
Technical indicators
Power Supply
Input voltage Poe IEEE 802.3af/802.3at type 1, class 3
24 VAC ±10%
12 VDC ±10%
Poe and auxiliary power can be connected simultaneously for redundant operation
Power consumption (DC) max. 13.4w
Power consumption (AC) max. 13.3w
Power consumption (POE) 11.4w maximum
sensor
Sensor total pixels 6 mp
Type (6 MP) 1 / 1.8 Inch CMOS
Pixels used (6 MP) 2112 x 2112 (4.5 MP)
Sensor total pixels 12 MP
12.3-inch (CMOS) type
Pixels used (12 MP) 3008 x 3008 (9 MP)
Video performance - sensitive
