Huawei c665d-z33 02352rca 5 million star level infrared spherical camera




Product features

1 / 2.7 "5 million CMOS

Support perimeter intrusion, heat map, parking detection, etc

Support automatic tracking function

Support image quality diagnosis

Support stream smoothing, adapt to different requirements of image quality and fluency in different scenes

Support traffic shaping, accurately control video coding instant burst, smooth video without packet loss

TCP acceleration enables the network to carry higher quality video stream

Huawei c665d-z33 image sensor: 1 / 2.7 "5 megapixel progressive CMOS; Maximum resolution: 2560 × 1920; Minimum illumination: Color: 0.005lux, black and white: 0.0005lux; Focal length: 5-165mm; Optical zoom ratio: 33; Horizontal rotation range: 0 °～ three hundred and sixty °; Vertical rotation range: - 15 °～ ninety °; Fill light: 150m; Compression coding: h.265/h.264/mjpeg; Behavior analysis: support; Exception detection: support; 3D positioning: -; Intelligent tracking: support; Face capture: support; Human detection: support; Vehicle identification: support; Power supply: AC24 V, Poe + (IEEE 802.3 at); Working temperature: - 30 ℃ ~ 60 ℃; Protection / riot / lightning protection: IP66, 6kV; 02352rca fastball 2317-3476 CN: c665d-z33 02352rca

technical parameter

Product model: c665d-z33

video camera

Image sensor: 1 / 2.7 "5 megapixel CMOS

Effective image size: 2560 (H) * 1920 (V)

Minimum illumination:

Color: 0.005lux (f1.2, AGC on, 1 / 30 shutter)

Black and white: 0.0005lux (f1.2, AGC on, 1 / 30 shutter)

Day and night mode: ICR / color / black and white

Shutter speed: 1 / 3S ~ 1 / 68250s

Gain control: automatic / manual

Wide dynamic range: 120dB

Backlight compensation: support, optional area

White balance: manual / automatic / automatic tracking

Strong light suppression: support

Image fogging: automatic / manual

Video anti shake: support

Day and night focus compensation: support

Lens & fill

Focal length: 5-165mm

Zoom: 33 times optical zoom, 16 times digital zoom

Maximum aperture: f1.6

Aperture type: p-iris

Light compensation distance: 150m

Yuntai

Rotation angle: horizontal 0 °～ three hundred and sixty °; Vertical-15 °～ ninety ° Horizontal rotation speed: keying speed: 0.1 ~ 160 °/ s. Preset speed: 240 °/ s

Vertical rotation speed: keying speed: 0.1 ~ 120 °/ s. Preset speed: 200 °/ s

Pan tilt scanning: pattern scanning / limit scanning / horizontal scanning / vertical scanning / random scanning / frame scanning / panoramic scanning

Watch: preset position / Cruise track / pattern scanning / horizontal scanning / vertical scanning / random scanning / frame scanning / panoramic scanning

function

Video compression format: h.265/h.264/mjpeg

Maximum resolution: 2560 × one thousand nine hundred and twenty

Frame rate: 30 / 25FPS, settable

Multi channel coding: three bit stream

Intelligent coding: extra265 / 264

Audio coding format: support g.711a/g.711u/g.726/opus

Audio communication: voice intercom, voice broadcast, voice on the road

Front end access protocol: onvif profile s / g / T, GB / T 28181 (20112016 protocol specification), GB 35114-2017, Huawei SDK, Huawei rest API

Network protocols: TCP, UDP, IPv4, IPv6, DHCP, DHCPv6, DNS, ICMP, ICMPv6, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, sip, ARP, SSL, NTP, SNMP (V1 / V2 / V3), 802.1x, QoS, DDNS

Security mode: user name and password authentication, support 802.1x, HTTPS security access

Media security: support KMC key encryption, support SDK stream aes256 encryption

Video Digital Watermarking: support fragile digital watermarking (MJPEG does not support)

Alarm linkage: alarm source: motion detection alarm / occlusion alarm / switch input alarm / intelligent analysis alarm

Linkage target: switch output / preset position / Cruise track / scan / SD card video / SD card capture / pre alarm recording

Intelligent function

Behavior analysis: fast mobile detection, legacy detection, move detection, cross line detection, intrusion detection, zone in / out zone detection, wandering detection

Anomaly detection: audio detection, audio steep rise and fall detection, scene change detection, virtual focus detection, heat map, personnel gathering

Face: face detection, face capture: support; Human detection: support

Vehicle: parking detection vehicle identification: support

Intelligent tracking: Panoramic automatic tracking, event linkage tracking, manual tracking

Interface

Network interface: one RJ45 10m / 100M Ethernet port

Alarm interface: 2 alarm inputs and 1 alarm output

Audio interface: 1 channel audio input, 1 channel audio output

Storage interface: provide microSD card slot, support microSDHC / microsdxc, support 256gb maximum capacity memory card

General specifications

Power supply: AC24 V, Poe + (IEEE 802.3at)

Power consumption: maximum power consumption is 23W, typical power consumption is 9.5W

Working temperature and humidity: - 30 ℃ ~ 60 ℃

Working humidity: 5% - 95% (no condensation)

Lightning protection grade: 6kV

Protection grade: IP66

Weight: equipment 4.0KG, package 5.3kg

Size: equipment 310 × two hundred and one point six × 201.6mm, package 400 × two hundred and ninety-five × 295mm
