Huawei m214d-ebi (3.6mm) 02352rkm (3.6mm / 6mm) 4 million behavior analysis cylindrical camera

Product features

1 / 2.7 "progressive scan CMOS

Support stream smoothing, adapt to different requirements of image quality and fluency in different scenes

Support traffic shaping, accurately control video coding instant burst, smooth video without packet loss

TCP acceleration enables the network to carry higher quality video stream

Embedded image quality diagnosis function

Support stream AES encryption

Huawei m214d-ebi (3.6mm) image sensor: 1 / 2.7 "4 megapixel progressive scan CMOS; maximum resolution: 2560 × 1440; Minimum Illumination: Color: 0.015lux, black and white: 0.0075lux; focal length: 3.6mm; fill light: 50m; compression coding: h.265/h.264/mjpeg; behavior analysis: support; anomaly detection: support; queue length detection: support; crowd density detection: support; power supply: DC12V; working temperature: - 30 ℃ ~ 60 ℃; Protection / riot / lightning protection: IP66, 4KV; 02352rkm cylinder machine 625-938 CN: m214d-ebi (3.6mm) 02352rkm

technical parameter

Product model: m214d-ebi (3.6mm / 6mm)

video camera

Image sensor: 1 / 2.7 "4 megapixel progressive scan CMOS

Effective image size: 2560 (H) * 1920 (V)

Minimum illumination:

Color: 0.015lux (f1.2, AGC on, 1 / 30 shutter)

Black and white: 0.0075lux (f1.2, AGC on, 1 / 30 shutter)

Day and night mode: ICR / color / black and white

Shutter speed: 1 / 3S ~ 1 / 68250s

Wide dynamic range: 120dB

White balance: Auto / auto tracking / manual

Strong light suppression: support

Image fogging: Auto / manual / off

Digital noise reduction: 2D / 3D noise reduction

Video anti shake: support

Lens & fill

Focal length: 3.6mm/6mm

Maximum aperture: f1.6

Aperture type: fixed aperture

Lighting distance: 50m

function

Video compression format: h.265/h.264/mjpeg

Maximum resolution: 2560 × 1440

Frame rate: 30 / 25FPS

Multi channel coding: three bit stream, support 1080p dual independent HD coding

Bitstream package: built in: high quality / balanced / low bandwidth / low pixel basic bitstream package

Intelligent coding: extra265 / 264

Front end access protocol: onvif profile s / g / T, GB / T 28181 (20112016 protocol specification), Huawei SDK, Huawei rest API

Network protocols: TCP, UDP, IPv4, IPv6, DHCP, DHCPv6, DNS, ICMP, ICMPv6, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, sip, ARP, SSL, NTP, SNMP (V1 / V2 / V3), 802.1x, QoS, DDNS, SMTP

Security mode: user name and password authentication, support 802.1x, HTTPS security access

Media security: only support SDK stream aes256 encryption

Video Digital Watermarking: support fragile digital watermarking (MJPEG does not support)

Alarm linkage: alarm source: mobile detection alarm / occlusion alarm / intelligent analysis alarm; linkage: SD card video / SD card capture / email sending / pre recording before alarm

Intelligent analysis

Behavior analysis: fast mobile detection, legacy detection, move detection, cross line detection, intrusion detection, zone in / out zone detection, wandering detection

Anomaly detection: image quality diagnosis, virtual focus detection, scene change detection, heat map

Crowd situation analysis: queue length, regional number of people statistics, traffic statistics

Interface

Network interface: one RJ45 10m / 100M adaptive Ethernet port

Storage interface: provide microSD card slot, support microSDHC / microsdxc, support 256gb maximum capacity memory card

General specifications

Power supply: DC12V

Power consumption: maximum power consumption 7W, typical power consumption 5W

Working temperature: - 30 ℃ ~ 60 ℃

Working humidity: 5% ~ 95% (non condensing)

Lightning protection grade: 4KV

Protection grade: IP66

Weight: equipment 0.59kg, package 0.9kg

Size: equipment 108 * 91 * 210mm; package 296 * 141 * 117mm
