Huawei Huawei c212a-i (3.6mm) 2 million star level infrared cylindrical camera
Product features
1 / 2.7 "progressive scan CMOS
Support h.265 encoding format, support dual independent 1080p HD encoding
High quality image performance under super low illumination, 24-hour HD monitoring
Strong light suppression, no loss of key information under strong light interference
120dB super wide dynamic, strong contrast scene to restore real details
Intelligent fog penetration to enhance image clarity in foggy scenes
Support fast configuration of code stream package
Intelligent extraction of metadata to provide massive metadata for Intelligent Applications
Powerful sec error correction, 20% network packet loss image is still smooth
Huawei Huawei c212a-i image sensor: 1 / 2.7 "2 megapixel scanning CMOS line by line; maximum resolution: 1920 × 1080; Minimum Illumination: Color: 0.005lux, black and white: 0.0005lux; focal length: 3.6mm; light supplement: 30m; compression code: h.265/h.264/mjpeg; behavior analysis: support; abnormal detection: support; power supply: DC12V; working temperature: 30 ℃ ~60 ℃; protection / riot / lightning protection: IP67, 4KV; 02352vlg barrel machine 384-576 cn: c212a-i (3.6mm) 02352vlg
technical parameter
Product model: c212a-i (3.6mm)
video camera
Image sensor: 1 / 2.7 "2 megapixel progressive scan CMOS
Effective image size: 1920 (H) * 1080 (V)
Minimum illumination:
Color: 0.005lux (f1.2, AGC on, 1 / 30 shutter)
Black and white: 0.0005lux (f1.2, AGC on, 1 / 30 shutter)
Day and night mode: ICR / color / black and white
Shutter speed: 1 / 3S ~ 1 / 68250s
Gain control: automatic / manual
Wide dynamic: 120dB, physical wide dynamic
Backlight compensation: support, optional area
Strong light suppression: support
Image fogging: Auto / manual / off
White balance: Auto Tracking / Auto / manual
Digital noise reduction: 2D / 3D noise reduction
Video anti shake: support
Day and night focus compensation: support
Lens & fill
Focal length: 3.6mm
Maximum aperture: f1.4
Light compensation distance: 30m
function
Video coding format: h.265/h.264/mjpeg
Maximum resolution: 1920 × 1080
Frame rate: 60 / 50 / 30 / 25FPS, settable
Video rate: 32kbps ~ 16mbps
Multi channel coding: three bit stream
Region clipping coding: sub stream one support
Intelligent coding: extra265 / 264
Audio coding format: g.711a/g.711u/g.726/opus
Audio communication: voice intercom, voice broadcast, voice on the road
Front end access protocol: onvif profile s / g / T, GB / T 28181 (20112016 protocol specification), GB 35114-2017, Huawei SDK, Huawei rest API
Network protocols: TCP, UDP, IPv4, IPv6, DHCP, DHCPv6, DNS, ICMP, ICMPv6, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, sip, ARP, SSL, NTP, SNMP (V1 / V2 / V3), 802.1x, QoS, DDNS
Security mode: user name and password authentication, support 802.1x, HTTPS digital certificate
Media security: only support SDK stream aes256 encryption
Video Digital Watermarking: support fragile digital watermarking (MJPEG does not support)
Alarm linkage: alarm source: motion detection alarm / occlusion alarm / switch input / intelligent analysis alarm linkage target: switch output / linkage SD card video recording / SD card capture / pre recording before alarm
Intelligent function
Behavior analysis: fast move detection, legacy detection, move detection, cross line detection, intrusion detection, zone in / out zone, wandering detection
Anomaly detection: audio detection, audio steep rise and fall, scene change detection, virtual focus detection, personnel gathering, heat map
Vehicles: parking detection
Interface
Network interface: one RJ45 10m / 100M adaptive Ethernet port
Audio interface: 1 channel audio input, 1 channel audio output
RS485 interface: one half duplex RS485 interface
Switch interface: 2 input / 1 output
Storage interface: provide microSD card slot, support microSDHC / microsdxc, support 256gb maximum capacity memory card
General specifications
Power supply: DC12V,
Power consumption: maximum power consumption 14.4w; typical power consumption 4W
Working temperature: - 30 ℃ ~ 60 ℃
Working humidity: 5% ~ 95% (non condensing)
Lightning protection grade: 4KV
Protection grade: IP67
Weight: equipment 0.59kg, package 0.9kg
Size: 108 × 91 × 210mm, package: 296 × 141 × 117mm
