Bosch nte-3502-f02l hemisphere camera 2MP HDR 120 ° IP66 ik10 IR
1080p definition, can provide clear image
Built in essential video for quick retrieval of related data
Multiple fully configurable h.265 data streams
High dynamic range (120 dB) for challenging bright and dark scenes
Built in infrared lighting, sight distance 15m (49ft)
Input voltage Poe IEEE 802.3af / 802.3 @ 1, class 3, 12 VDC ± 30%
Power consumption (typical / maximum) POE: 3.5 w / 10.5 w 12 VDC: 3.1 w / 9.5 w
Sensor type 1 / 2.8 inch CMOS
Effective pixels 1920 (horizontal) x 1080 (vertical)
Color 0.1 LX
Black and white 0.02 LX
Infrared on 0.0 LX
High dynamic range 120 dB WDR
103 DB measured according to IEC 62676 Part 5
Lens type 2.3mm fixed, f2.22.8mm fixed, f1.6
Day night switchable infrared filter
Field of view 2.3mm: 132 ° x 77 ° (horizontal x vertical) 2.8mm: 107 ° x 57 ° (horizontal x vertical)
Distance 15 m (49 ft)
LED indicator 2 LED indicators, 850 nm
The infrared intensity can be adjusted at will
Video compression formats h.265, H.264, M-JPEG
Sensor mode 30 FPS, HDR, 1920 x 1080, 25 FPS, HDR, 1920 x 1080
Stream multiple configurable H.264 or h.265 and M-JPEG data streams with configurable frame rate and bandwidth. Region of interest (ROI
GOP structure IP
Encoding interval 1 to 30 FPS
