Bosch nfn-70122-f0a fixed spherical camera 12MP, 360 °, IVA, ceiling mounted
Product No.: nfn-70122-f0a | product No.: f.01u.314.921
12MP / 30 FPS sensor for smooth motion and high quality details
Edge or client twist correction for easy integration
Intelligent video analytics for panorama
Embedded ceiling design, hidden and beautiful
Easy to spray, suitable for concealed installation
Revit file available
Select product model
Main specifications
Power supply Ethernet power supply rated 48 VDC
Poe IEEE 802.3af (802.3at type 1)
Current consumption (POE) up to 200 Ma
Type 1 / 2.3 inch CMOS
Sensor total pixel 12MP
Pixels used (180 ° type) 3648 x 2160 (8mp)
Pixels used (360 ° type) 2640 x 2640 (7mp)
Color 0.55 LX
Black and white 0.18 LX
Color 0.46 LX
Black and white 0.15 LX
Dynamic range 92 DB WDR (+ 16 dB IAE)
Video compression H.264 (MP); M-JPEG
Multiple configurable H.264 and M-JPEG data streams, configurable frame rate and bandwidth. Multi channel ROI for edge distortion correction
The overall IP latency is at least 120 ms and at most 340 Ms
Encoding interval 1 to 25 [30] IPS
The encoder area has eight independent areas, which are used to set the encoder quality to optimize the bit rate.
Video 1 channel circular image, 3640 x 2160
Video 2-channel panorama, 2688 x 800
E-PTZ 2048 x 1152
