Bosch Bosch npd-6001a npd-6001b medium span, high power Poe, single port, AC input
Commodity No.: npd-6001a| product No.: f.01u.275.994
Stop production



It supports high power POE / poh and meets IEEE 802.3af and IEEE 802.3at standards

60 W
Installation to walls, shelves, worktables, desktops and other devices
Current tab: technical specifications
Product components
Data download
Main specifications
Connector shielded RJ-45 100 base TX Ethernet Poe + + EIA 568a and 568B
Data transmission for 10 / 100 Ethernet provides data on data pair 1 / 2 and 3 / 6
Input voltage 100 to 240 VAC, 50/60 Hz
Output voltage 54-57 VDC (rated)
Input current npd-6001a (60 W):1.2 anpd-9501a (95 w):1.35 a (max)
High power Ethernet power supply (high power POE) output pin allocation and polarity: 4 pairs of power - data pair 1 / 2 (–) and 3 / 6 (+) - data pair 7/8 (–) and 4/5 (+) user port power: 60 W maximum (for npd-6001a) 95 w (for npd-9501a)
No surge protection
Operating temperature at 95 W: - 10 ° C to +40 ° C (+14 ° f to +104 ° f) at 60 W-10 ° C to +45 ° C (+14 ° f to +113 ° f) at 30 W-10 ° C to +55 ° C (+14 ° f to +131 ° f)
Storage temperature - 20 ° C to +70 ° C (-4 ° f to +158 ° f) (npd-6001a and npd-9501a)
Working humidity npd-6001a (60 W): 90% relative humidity, non condensing npd-9501a (95 w): 10% – 95%, non condensing
Storage humidity npd-6001a (60 W): 95% relative humidity, 95% non condensing npd-9501a (95 w): 5% – 95%, non condensing
Dimensions (W x H x L) 87.9 mm x 43 mm x 166 mm (3.46 in X 1.68 in X 6.53 in.)
Weight 400 g (0.88 lbs)
Installation to walls, shelves, worktables, desktops and interconnections
Number of ports one (1)
Pass data rate 10/100/1000 Mbps
Recommended maximum cable length distance between network source and terminal should not exceed 100 meters (333 feet)
System indicator AC power (green) channel power (green and orange)
